Ultrasonic Tube Filling Machine uses intelligent digital ultrasonic technology to enable molecules on the surface area of the tubes to be fused together by ultrasonic friction. Intelligent digital ultrasonic welding avoids the disadvantages that weak welding causes due to foreign matter adhering to the walls. BZGF-U50 fully automatic ultrasonic tube filling and sealing machine is the perfect choice for pharmaceutical and cosmetic cream or other cream products. This machine is a high-tech product which successfully developed and designed by adopting advanced technology from abroad and strictly meets GMP requirements.
Ultrasonic Tube Filling Machine is advanced equipment for plastic tube filling and sealing. It uses ultrasonic seal the plastic tube heat shock effect produced by the transducer and to rapidly melt adhesive. No need to add any supplements, even if the surface contamination, but also will not affect the sealing result. We can also supply heating sealing tube filling sealing machines.
1. It’s applicable to toothpaste, cosmetics, pharmaceutical, food, industry product, and other soft tube filling and sealing.
2. Extensional organization of the machine is made of aluminum alloy and stainless steel.
3. The working platform is easy to operate that is an independent man-machine operating interface and can be a two-dimension direction adjustment.
4. The ultrasound power supply adopts Taiwan movement circuitry, ultrasound parts use famous brands.
5. It’s with the function of overload protection, phase difference protection, and power-fail protection
6. The ultrasound output power is big enough to ensure the sealing quality of different kinds of material and specifications soft tubes.
7. It’s with the function of automatically cutting.
|Tube Length||50-200mm (customized)|
|Tube Diameter||10-50mm (change molds)|
|Filling Volume||8-250ml (change pump)|
|Machine Dimension||1200*800*1600mm (L*W*H)|
